VOLVO PENTA TWD1744GE
1500rpm, 750kVA at Prime, 825kVA at Standby
| MODEL_VOLVO_PENTA | ORIGIN |
| Volvo Penta TWD1744GE TTTT | SWEDEN |
Generator engine Volvo Penta TWD1744GE
(Volvo Penta engine for sale, used for 750kva generator)
– Original: VOLVO PENTA – VOLVO GROUP
– Made in: SWEDEN
– Model: TWD1744GE
– Prime: 1500Rpm – 645kW / 1800Rpm – 682kW
– Stand by: 1500Rpm – 710kW / 1800Rpm – 750kW
– 4 Stroke diesel engine with direct injection
– Turbocharged
Number of cylinders Volvo Penta TWD1744GE
Volvo TWD1744GE
– 6 cylinders
– Displacement: 17,26 liter
– Bore: 149 mm
– Stroke: 165 mm
– Firing order: 1-5-3-6-2-4
– Compression ratio : 16.5:1
Starter system
Volvo Penta TWD1744GE
– Electric started
– Alternator:
+ Made by: Bosch
+ Output : 80A
+ Automatic pressure regulator
– Starter motor:
+ Made by : Mitsubishi Electric
+ Type: 105P70
+ Power: 7 kW
+ Voltage: 24V
See more: Volvo Penta TAD840GE
See more: Volvo Penta TAD1346GE
Shutdown system
– Electric shutdown
– 24VDC coil to stop motor
Cooling system Volvo Penta TWD1744GE
– Cooled by circulating water combined with axial fans
– Cooling water capacity : 56 liter
– Cooling water tank cap is able to protect over pressure in cooling water tank
– Fan power : 21 kW
– Protection barrier
Exhaust system
– Silent pipe
– Emissions escaped Vietnam standards for engine exhaust
Fuel system Volvo Penta TWD1744GE
– Fuel transfer pump: hand pump (primer pump) and machine pump (high pressure pump)
– Speed governor : Electronic EMS2.4
Fuel type
Diesel
Lub oil system Volvo Penta TWD1744GE
– Forced lubrication + self swing
– Lubricating oil filter installed in the proper position, replace easily
– Lubricating oil capacity: 52 liter
– Lubricating oil consumption: 0,08 liter/h
Fuel consumption
| Prime Power | ||
| Load % | 1500 Rpm | 1800 Rpm |
| 25 | 211g/kWh | 225g/kWh |
| 50 | 197g/kWh | 202g/kWh |
| 75 | 194g/kWh | 197g/kWh |
| 100 | 194g/kWh | 196g/kWh |
| Standby Power | ||
| Load % | 1500 Rpm | 1800 Rpm |
| 25 | 208g/kWh | 222g/kWh |
| 50 | 195g/kWh | 200g/kWh |
| 75 | 195g/kWh | 196g/kWh |
| 100 | 194g/kWh | 197g/kWh |
Radiators
Circulating heat exchanger in copper
Lọc gió (Air filter)
– Dry paper filter, can be removed, maintained and replaced easily
– Efficient: 99,99 %
Information can be changed by Volvo Penta without notice.
